Smarter Tank Management Starts Here— Advanced Capacitive Level Sensor

IconsIconsIcons
  • Low Power Draw: 9–30 VDC @ 30 mA
  • Programmable Alarms & Intelligent Switching
  • Pre-Calibrated for Cross-Medium Accuracy
  • Smart Outputs: RS485 Modbus, 4–20 mA, 0–5 V
  • Industrial-Grade Capacitive Level Sensor with 99% Accuracy
  • Multi-Medium Support: Water, Oil, Chemicals & More
  • High-Resolution Depth Measurement: 1 mm Precision
  • Optional ATEX & IECEx Certification for Hazard Zones
Capacitive level transducer providing reliable, continuous level detection

Advanced Liquid Level Measurement

Advance
Icons

Measurement Range: 100 mm to 7500 mm

Icons

Accuracy: 0.25% FSR

Icons

Resolution: 1 mm

Icons

Non-Linearity: 0.01%

Icons

Repeatability: ±0.05%

Icons

Temperature Drift: 100 PPM/°C

Icons

Calibration: Factory & Field Supported

Industrial Power Efficiency

Reliable operation across wide voltages with ultra-low power usage for demanding industrial environments.

Capacitive level transducer providing reliable, continuous level detection
Icons

Power Input Voltage:9–30 VDC

Icons

Current Consumption:30 mA

Multiple Outputs

Unified sensor, versatile outputs for industrial compatibility.

Multi-output capacitive level sensor with analog and RS485 communication for industrial automation
Icons

RS485 Modbus

Icons

4–20 mA

Icons

Analog 0–5 V

Smart Depth Sensing Meets Intelligent Switching

Measure tank depth with pinpoint accuracy and activate real-time control logic for critical level thresholds.

High-precision capacitive transducer for measuring tank depth in power and process industries

High-level, low-level, or custom triggers—you're in charge.

Switch Graphic

Switch Output for
Low and High

Calibrated for Every Medium

No matter the medium — Our Capacitive Level Sensor comes pre-calibrated for cross-medium performance,ensuring unwavering precision and effortless deployment from day one.

GlowWater

Water

GlowOil

Oil

GlowDiesel

Diesel

Engineered for Hazard Zones

Explosion-proof capacitive level sensor for fuel and chemical tank monitoring

Available with ATEX and IECEx certifications, our capacitive liquid level sensor delivers precise performance where safety and compliance are non-negotiable.

Engineered for Extreme Temperatures

Designed for reliable performance in the toughest industrial conditions, withstanding humidity up to 90% RH (non-condensing)

Cold Icons
Hot Icons

Industrial-Grade Protection

Engineered for reliable performance in demanding industrial operations.

Waterproof and dustproof capacitive sensor with IP67-rated enclosure
Icons

IP65 / IP67 ingress protection

Icons

Die-cast aluminum, PU powder-coated

Flexible Mounting Options

Seamless installation with standard or custom mounting.

IconsIconsIcons
Icons

Standard: 60 PCD Flange, 120° spacing

Icons

Optional: Custom mounting available

Icons

Probe Construction: Aluminum / SS316L

Icons

Cable Entry: Dual PG11

Non-Linear Calibration – Multipoint for Complex Tanks

Supports multipoint calibration for irregular tank shapes, ensuring accurate measurement at every critical volume point.

Multipoint calibrated capacitive level sensor for precise industrial tank monitoring

Linear Calibration – 2-Point Precision

Supports 2-point calibration at low and high levels for a perfectly linear tank output.

Linear calibration capacitive level sensor ensuring high-accuracy level detection

Key Benefits of Our Capacitive Level Sensor

Precise Detection

Precise Detection

±0.5% accuracy and 1 mm resolution for reliable capacitive liquid level detection.

Multi-Medium Ready

Multi-Medium Ready

Works seamlessly as a capacitive water, oil, and chemical level sensor.

Easy Integration

Easy Integration

Supports RS485 Modbus, 4–20 mA, and 0–5 V for SCADA and IoT systems.

Hazard-Safe

Hazard-Safe

ATEX & IECEx certified capacitive type level transmitter for explosive zones.

Smart Switching

Smart Switching

Functions as a capacitive level switch with programmable alarms.

Versatile Integration

Versatile Integration

Seamlessly adapts to various industrial systems for enhanced flexibility.

Product Specifications

Comprehensive details for performance, reliability, and integration.

Ultralevel Max

Caplevel Sensor

Accurate non-conductive liquid level monitoring with rugged protection.

Enquiry Now
spec-icons

MEASUREMENT PERFORMANCE

  • Sensing Range: 10 mm to 5 m (application dependent)
  • Measurement Medium: Diesel, oils, and other electrically non-conductive liquids
  • Resolution: 1 mm
  • Accuracy: ±0.5% of Full-Scale Range (FSR)
  • Repeatability: ±0.05% of FSR
  • Long-Term Stability: ±0.01% of FSR
  • Temperature Drift: 100 ppm/°C
  • Sample Rate: 20 Hz
  • Dielectric Constant Range: ≥ 2.0 (non-conductive liquids/materials)
  • Response Time: 200 ms

COMMUNICATION & OUTPUT

  • Output Signal: RS485 (Modbus), 0–5 V Analog, 4–20 mA
  • Calibration: Factory and field calibration possible

POWER SUPPLY

  • Input Voltage: 9–30 VDC
  • Current Consumption: 30 mA

OPERATING ENVIRONMENT

  • Operating Temperature: –10 °C to +75 °C
  • Humidity Range: 10% – 90% RH (non-condensing)
  • Ingress Protection: IP65 / IP67 (electronics compartment)
  • Explosion Protection: Optional ATEX / IECEx-certified modules available upon request
  • Environment Suitability: Indoor, outdoor, industrial, marine, hazardous environments

MECHANICAL

  • Mounting Options: Standard: 60 PCD Flange, 120° spacing with 3 holes (4.2 mm)
  • Optional: Custom mounting available
  • Probe Construction: Aluminum or SS316L (optional)
  • Cable Entry: PG11, two nos
  • Enclosure: Die-cast Aluminum with PU powder coating

Use Cases

Industrial Storage Tank
Use Case

Industrial Storage Tank

Water Level monitoring
Use Case

Water Level monitoring

Fuel tank monitoring
Use Case

Fuel tank monitoring

Smart silos
Use Case

Smart silos

Water reservoir monitoring
Use Case

Water reservoir monitoring

Diesel Tank Monitoring
Use Case

Diesel Tank Monitoring

Tell Us About

Business Requirements

Select Your Country
+91
Enter Your Business Type

FAQ

What is a capacitive level sensor?

A capacitive level sensor is a non-contact device that measures liquid levels, including water, oil, and chemicals, by detecting changes in capacitance.

How accurate is a capacitive liquid level sensor?

Our capacitive liquid level sensor provides ±0.5% FSR accuracy with 1 mm resolution for precise tank monitoring.

Can it measure non-conductive liquids like oil or diesel?

Yes. This capacitive oil level sensor is designed for non-conductive liquids, fuels, and solvents with high accuracy.

Is the capacitive water level sensor safe for hazardous areas?

Absolutely. Optional ATEX and IECEx-certified modules make it suitable for explosive and hazardous industrial environments.

Which industries use capacitive liquid level sensors?

Common applications include water treatment, oil & gas, chemicals, pharmaceuticals, and food & beverage for reliable fill level monitoring.

Does it support integration with industrial systems?

Yes. The sensor offers RS485 Modbus, 4–20 mA, and 0–5 V outputs for seamless integration with SCADA, IoT, and automation platforms.

Can the sensor act as a level switch?

Yes. The capacitive level switch functionality allows programmable high/low alarms and intelligent switching for tank automation.
